The height, curve and outline of a women's standing collar need to suit the garment pattern. KANGYE's women's standing-collar press supports the collar on a shaped mold for pressing and setting its form. Different collar styles should be checked with a sample garment to confirm mold fit and define the pressing requirements for the intended collar shape.
KANGYE garment pressing equipment
Women’s standing-collar pressing and setting machine
| Control system | Automatic touch-screen PLC |
|---|---|
| Pressing force (kg, as listed) | 150kg |
| Steam supply / consumption | 0.4-0.6MPa (18kg/h) 1/2" |
| Compressed air supply / consumption | 0.4-0.6MPa (15L/min) 8mm |
| Electrical supply | 220V/1ph/50HZ |
| Condensate outlet | 1/2" |
| Net weight | 380kg |
Reference values for comparable equipment. Confirm the actual configuration with KANGYE.
Mold and equipment customization support
We support customized mold and equipment solutions based on your sample garments, patterns and production process. Final fit and scope are confirmed through sample trials and technical discussion.
Pressing area
CollarDiscuss the mold fit
Share your sample garment and pressing requirements. We can review how the mold fits before discussing a custom mold.
